The measurement range of 1.20~225.00mm ,1.00~300.00mm combined with ultrasonic wave velocity measurement function of 1000~9999m/s provides accurate measurement readings.
Widely used in various precise measurements for different hardware/parts in industrial realm. One of its important applications is to monitor the level decreasing thickness during operation of various and pressure container.
Diffusely applied in manufacture fields, metal processing as well as commercial inspection and can be applied for materials that conduct and reflect constant sonic velocity.
Features: * Display: Color Screen LCD * Working frequency:5MHz
* Measuring range: 1.00 to 300.0mm(steel)
* Minimum limit for tube measuring:
Φ15*2.0mm(Φ6mm transducer)
Φ20*3.0mm(Φ10mm transducer)
* Accuracy:+/-(0.05%H+0.04)mm,H denotes the measured thickness.
* Resolution: 0.01mm(1.00 to 00.00mm)
0.1mm(100 to 300mm)
* Sound velocity range: 1000 to 9999m/s
Thickness≤25mm,accuracy of velocity:+/-1.25mm/Hx100%
Thickness≥25mm,accuracy of velocity:+/-5%
* Operation temperature: 0ºC to 40ºC
Relative humidity:<90%
Do not apply in violent vibration/erosive material Avoid impact and humidity
* Power supply: 3*1.5V NiMH battery or 5V 1A power adapter
