Technical parameter
|
Technical specification
|
|||
|
Vibration pickup
|
Piezoelectric ceramic accelerometer(shear-type)
|
|||
|
Measurement range of acceleration
|
0.1~199.9m/s2peak
|
|||
|
Measurement range of velocity
|
0.1~199.9mm/s rms
|
|||
|
Measurement range of displacement
|
0.001~1.999mm p-p Velocity and displacement range is limited by acceleration199.9m/s2
|
|||
|
Measurement accuracy
|
±5% ±digits
|
|||
|
Measurement frequency range of acceleration
|
10Hz~1KHz(LO) 1KHz~15KHz(HI)
|
|||
|
Measurement frequency range of velocity
|
10Hz~1KHZ (LO)
|
|||
|
Measurement frequency ange of displacement
|
10Hz~1KHz (LO)
|
|||
|
Displays update cycle
|
1 seconds
|
|||
|
LCD display
|
3 1/2 digits display
|
|||
|
Single output
|
AC output 2 V peak (display full scale) Load impedance 10KΩ or more earphones can be connected
|
|||
|
Power supply
|
9V battery
|
|||
|
Stand-by current
|
≤15μA
|
|||
|
Operating current
|
≤25mA
|
|||
|
Battery life
|
20H continuous use
|
|||
|
Auto power-off function
|
Turns off automatically after 60 seconds
|
|||
|
LCD backlight function
|
7 seconds
|
|||
|
Operating temperature range
|
0~40C
|
|||
|
Operating humidity range
|
30~90%RH
|
|||
|
Low battery indication
|
6.4V±0.2V
|
|||
|
Dimensions
|
72×35×145mm
|
|||
|
Weight
|
229g (not including battery )
|
|||
|
Temperature range
|
-10ºC~80ºC
|
|||
|
Temperature accuracy
|
±2ºC
|
|||
