| Brand Name: | Bestone,HTI |
| Model Number: | HT-C523 |
| MOQ: | 50 |
| Price: | Negotiable |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T,Western Union |
Lightweight and portable with plug-and-play functionality. Suitable for HVAC maintenance, electrical and building inspection, water pipe leakage detection, printed circuit board inspection, night pet search, and more, making potential hazards easily detectable.
Includes white heat, black heat, red heat, aurora, iron red, medical, dim light, rainbow, golden glow, jungle, golden red, and blue cold (Android version includes the last two as pseudo-colors). Provides users with choices for different scenarios, offering sharper hierarchy and instant risk identification.
ISR super-resolution with AI pixel doubling delivers sharp details without temperature loss and clear edges of small targets. Intelligent dark noise suppression captures even small temperature differences at long distances, doubling equipment working efficiency.
Compatible with both Android and Apple systems, eliminating concerns about system incompatibility. Allows all team members to use their mobile phone systems and enables alternating use of individual devices.
| Model Number | HT-C523 |
| Detector Type | Vanadium oxide non-cooled focal plane |
| Infrared Resolution | 256×192 |
| ISR Up Sampling | 512×384 |
| Visible Light Resolution | 1600×1200 |
| Lens Focal Length | 3.2mm F1.1 |
| NETD | ≤50mk@25℃, F#1.0 |
| Pixel Size | 12μm |
| Infrared Response Band | 8~14μm |
| Frame Rate | ≤25Hz |
| Field of View | 56°(H)×42°(V) |
| Focus Adjustment Method | Fixed focal length |
| Pseudo-Color Mode | White heat, black heat, red heat, aurora, iron red, medical, dim light, rainbow, golden glow, jungle, golden red, blue cold (Android version includes last two as pseudo-colors) |
| Image Display Mode | Center point, highest temperature, lowest temperature, point, line, area |
| Temperature Measurement Range | -20℃~+550℃ |
| Temperature Measurement Accuracy | ±2℃ or ±2% |
| Temperature Measurement Distance | 0.3m~3m |
| Image Alarm | Support |
| Image/Video Format | JPG/MP4 |
| Language | Chinese, English |
| External Interface | Type-C |
| Working Temperature | -20℃ to +50℃ |
| Storage Temperature | -45℃ to +75℃ |
| Protection Level | IP54 |
| Drop Protection Grade | 1m |
| Product Size | 57mm×32mm×11.5mm |
| Product Weight | 27g±1g |
