| MOQ: | 1 |
| Model No. | Gas Detected | Range |
| SACD4 | CH4 | 0.00-5.00)%vol |
| CO | (0-1000)PPM | |
| O2 | (0.0-30.0)%VOL | |
| H2S | (0-100)ppm | |
| SACD4 | LEL | (0-100)%LEL |
| CO | (0-1000)PPM | |
| O2 | (0.0-30.0)%VOL | |
| H2S | (0-100)ppm | |
| SACH4-O2 | CH4 | (0.00-4.00)%VOL |
| O2 | (0.0-30.0)%VOL | |
| SACH4-CO | CH4 | (0.00-4.00)%VOL |
| CO | (0-1000)PPM | |
| SACO-O2 | CO | (0-1000)PPM |
| O2 | (0.0-30.0)%VOL | |
| SAO2-CO2 | O2 | (0.0-30.0)%VOL |
| CO2 | (0.00-5.00)%vol | |
| SACH4-CO2 | CH4 | (0.00-5.00)%vol (0-100%)vol |
| CO2 | (0.00-5.00)%vol (0-100%)vol | |
| SAZQ | CH4 | (0-100%)vol |
| CO2 | (0-100%)vol | |
| H2S | (0-100)ppm | |
| CD3A | CH4 | (0.00-5.00)%vol |
| CO | (0-1000)ppm | |
| O2 | (0.0-30.0)%VOL | |
| CD3B | CH4 | (0.00-5.00)%vol |
| O2 | (0.0-30.0)%VOL | |
| H2S | (0-100)ppm | |
| CD3C | CH4 | (0.00-5.00)%vol |
| CO | (0-1000)ppm | |
| H2S | (0-100)ppm | |
| CD3D | CO | (0.00-5.00)%vol |
| O2 | (0.0-30.0)%VOL | |
| H2S | (0-100)ppm | |
| SANO2-CO2 | NO2 | (0-50)ppm (0-100)ppm |
| CO2 | (0.00-5.00)%vol |
| Gas Detected | Range | Resolution | Respond Time | Standard Testing Gas | Error |
| O2 | (0.0-25.0)%VOL (0.0-30.0)%VOL | 0.1%VOL | ≤35s(T90) | (0.0-5.0)%vol:5.0%vol | ±0.5%vol |
| (5.0-30.0)%vol:12.5%vol,21.0%vol,25.0%vol | ±3%FS | ||||
| CO | (0-1000)PPM | 1ppm | ≤45s(T90) | (0-20)ppm:24ppm | ±2ppm |
| (20-100)ppm | ±4ppm | ||||
| (100-500)ppm:350pppm | ±5%of STG | ||||
| (500-1000)ppm:500ppm,750ppm | ±6%of STG | ||||
| SO2 | (0-50)ppm | 0.1ppm | ≤45s(T90) | 10ppm,25ppm,40ppm | ±5%FS |
| NO | (0-250)ppm | 0.1ppm | ≤45s(T90) | 50ppm,100ppm,150ppm | ±5%FS |
| H2S | (0-100)ppm | 1ppm | ≤45s(T90) | (0-49)ppm:25ppm | ±3ppm |
| H2 | (0-1000)ppm | 1ppm | ≤45s(T90) | 250ppm,500ppm,750ppm | ±5%of STG |
| NO2 | (0-20)ppm | 0.1ppm | ≤45s(T90) | 5ppm,10ppm,15ppm | ±5%FS |
| NH3 | (0-100)ppm (0-1000)ppm | 1ppm | ≤45s(T90) | (0-100)ppm:25ppm,50ppm,75ppm | ±5%FS |
| (0-1000)ppm:250ppm,500ppm,750ppm | |||||
| CL2 | (0-10)ppm | 0.01ppm | ≤45s(T90) | 3ppm,5ppm,7ppm | ±5%FS |
| IRCH4 | (0.00-5.00)%vol (0-100%)vol | 0.01%vol | ≤50s(T90) | (0.00-1.00)%vol:0.5%vol | ±5% of RDC |
| (1-100)%vol:25%vol,50%vol,100%vol | |||||
| O3 | (0-1)ppm | 0.05ppm | ≤45s(T90) | ||
| C2H4O | (0-10)ppm | 0.1ppm | ≤45s(T90) | ||
| Catalytic CH4 | (0.00-4.00)%CH4 | 0.01%CH4 | ≤20s(T90) | (0.00-1.00)%vol:0.5%vol | ±0.10%vol |
| (1.00-3.00)%vol:2.00%vol,3.00%vol | ±0.10%of TV | ||||
| (3.00-4.00)%vol:3.5%vol | ±0.30%vol | ||||
| LEL | (0-100)%LEL | 1%LEL | ≤20s(T90) | 10%LEL,20%LEL,40%LEL,60%LEL,70%LEL | ±5%FS |
| IRCO2 | (0-5000)ppm (0.0-5.0)%vol (0-100)%vol | 1ppm/0.01%vol | ≤50s(T90) | (0-0.5)%vol:0.1%vol,0.2%vol,0.5%vol | ±0.10%vol |
| (0.5-5.0)%vol:1.0%vol,2.5%vol,0.5%vol | ±(0.05%vol+5%of STG) | ||||
| (5-100)%vol:25%vol,50%vol,100%vol | ±10%of STG | ||||
| C4H10 | (0-100)%LEL | 1%LEL | ≤20s(T90) | 10%LEL,20%LEL,40%LEL,60%LEL,70%LEL | ±10%FS |
