| MOQ: | 1 |
| Price: | 345 |
Infrared thermal imaging cameras are widely used in many fields such as medical, public security, fire protection, archaeology, transportation, agriculture and geology. It is an ideal choice for electricians and maintenance technicians to quickly locate problem areas.
| Infrared | |
| Infrared image resolution | 256x192 |
| Detector type | Vanadium oxide uncooled infrared focal plane |
| Focal length | 3.2mm |
| Working Wavelength Range | 8-14μm |
| Pixel spacing | 12μm |
| NETD | <50mK@25ºC, @F/1.0 |
| Image frame rate | ≤25Hz |
| Angle of view | 56°(H)x42°(V) |
| Focusing mode | Free Focus |
| Display | |
| Contrast adjustment | Supported |
| Image fusion degree | Supported |
| Brightness | Supported |
| Picture in pictures | Supported |
| Palettes | White hot, sepia, iron bow, rainbow, night, aurora, red hot, jungle, medical, and black hot |
| Hot spot tracking | Supported |
| Temperature measurement function | |
| Temperature measurement method | Point, line and regional temperature measurement |
| Temperature measurement range | -20ºC~120ºC and 120ºC-550ºC |
| Temperature measuring distance | 0.25m-30m |
| Temperature measurement accuracy | 300°C to 550°C; ±4% ;-15°C to 300°C;±2°C or reading ±2%;-20°C to15°C;±4°C |
| System function | |
| Power consumption | ≤1.5W |
| Endurance time | ≥2H |
| Camera/video | Supported |
| Picture/video format | JPG/MP4 |
| Language | Chinese, English |
| External interface | USB Type-C, DC5V power supply |
| WIFI | Supported |
| Protection level | IP54 |
| Power supply | 1000mAh chargeable lithium battery |
| Work/storage environment | |
| Operating Temperature Range: | -10ºC to +50ºC |
| Storage Temperature Range: | -20ºC to +70ºC |
| Size/weight | |
| Product size | 152x35x35mm |
| Weight: | 210g |
