| Brand Name: | Bestone,Benetech |
| Model Number: | GM505,GM510,GM511,GM520,GM522,GM525 |
| MOQ: | 40 |
| Price: | EXW US$35~US$69 |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T,Western Union |
With 11 selectable units: bar, mbar, Kpa, Kgf/cm², mmHg, cmH2O, Ozf/in², Psi, inHg, inH2O, ftH2O, this unit features Data Hold/Data Correction/Auto Off and connection with PC via APP for data access.
Pressure Manometer can be widely used to measure fan and blower pressure, filter resistance, wind speed, furnace pressure, orifice differential pressure, etc. It is also used for air gas ratio control and automatic valve control during combustion, as well as blood pressure and respiratory pressure monitoring in healthcare equipment.
| Model | GM505 | GM510 | GM511 | GM520 | GM522 | GM525 |
|---|---|---|---|---|---|---|
| Measuring range | ±2.49kPa | ±10kPa | ±10kPa | ±35Kpa | ±100Kpa | ±35Kpa |
| Precision | ±0.3%FSO (25℃) | |||||
| Repeatability | x | ±0.2% | ||||
| Linear/lag | x | ±0.29%FSO | ||||
| Reaction time | 0.5S | |||||
| Operating temperature | 0~50°C | |||||
| Storage temperature | -10~60°C | |||||
| Beyond positive pressure range | Err.1 | |||||
| Beyond negative pressure range | Err.2 | |||||
| Power supply | 1.5V AAA battery x 4pcs | |||||
| Weight | 277.8g (included batteries) | 232.5g (included batteries)(only for GM525) | ||||
| Size | 171.4*38*76.5 mm | 144*55*29.4+278*36*36mm(only for GM525) | ||||
